What is system integration?

System integration, also called IT integration or enterprise integration, is the process of linking different computing systems, software apps, and data sources within an organization to function as a unified whole. It encompasses data sharing, application connectivity, and process alignment across diverse systems, ensuring interoperability and seamless communication. By enabling systems to operate collectively, system integration enhances data accuracy, process efficiency, and scalability, providing a coherent technological ecosystem that supports strategic objectives and optimizes cross-functional workflows.

Common types of system integration solutions:

1. Point-to-Point Integration (P2P)

Point-to-Point (P2P) integration is a simple, direct connection between two systems or applications, allowing them to communicate with each other without intermediaries. In this setup, each system has its own integration logic to connect to other systems individually, making it straightforward for limited integrations but challenging to scale as the number of systems grows.

For example, in a retail business, a Point-to-Point integration might connect an e-commerce platform directly to a payment processor, or an inventory system to a shipping provider. If additional systems need to connect, each one requires new, custom integration, which can result in a complex and difficult-to-maintain "spaghetti architecture."

P2P integrations are often used for specific, high-priority use cases where quick setup is needed. However, as an organization grows, P2P can become inefficient, and more scalable architectures like hub-and-spoke or ESB are typically preferred.

Example: A small business integrates its online store with its inventory system and accounting software. Each integration is custom-built, such as connecting the store's order data directly to the inventory and accounting systems.

2. Hub-and-Spoke (Message Broker Architecture) Integration

Hub-and-Spoke, also known as Message Broker Architecture, is an integration model in which a central hub (the message broker) mediates all communications between connected systems (the spokes). In this model, systems do not connect directly to one another; instead, they send and receive messages through the central hub, which routes, transforms, and handles the messages as needed. This architecture is particularly useful for managing complex integrations where multiple systems need to interact with each other, often asynchronously.

Technologies using Hub-and-Spoke integration include Enterprise Service Buses (ESBs) like MuleSoft and IBM App Connect, which manage communication across systems. Message brokers such as Apache Kafka and RabbitMQ route and transform messages between applications. iPaaS platforms like Dell Boomi and Azure Logic Apps use this model to connect cloud and on-premise systems, while data integration tools (Informatica, Talend) facilitate data movements centrally. API management platforms (Apigee, WSO2) manage API traffic in a centralized hub, and IoT platforms (AWS IoT Core, Azure IoT Hub) aggregate data from multiple devices. This architecture simplifies large-scale integration by centralizing communication and management.

Key Components of Hub-and-Spoke Integration

1. Hub (Message Broker): The hub is a central processing unit that manages all message exchanges. It performs tasks such as message routing, transformation, and filtering based on pre-defined rules.

2. Spokes (Connected Systems): Each system (or application) is connected to the hub rather than directly to other systems. These spokes send data to and receive data from the hub, which eliminates the need for point-to-point connections.

Advantages of Hub-and-Spoke Integration

• Simplified Connections Systems only need to connect to the hub, reducing the number of individual connections needed, which simplifies integration and maintenance.

• Centralized Management All message transformations, routing, and error handling are managed centrally, making it easier to monitor and control data flows.

• Scalability and Flexibility Systems can be added, removed, or modified without affecting other systems, as long as they comply with the broker’s message standards.

• Decoupling of Systems Systems don’t need to know about each other’s specific data formats or protocols since the hub manages data transformations.

Example Use Case

In a retail organization, a hub-and-spoke architecture could connect order processing, inventory management, customer relationship management (CRM), and shipping systems. If an order is placed, the CRM, inventory, and shipping systems receive notifications and data updates from the hub without needing direct communication lines between each system.

This architecture is commonly used in industries that require reliable, centralized message handling with the ability to scale as systems are added or removed.

3. Enterprise Service Bus (ESB)

Enterprise Service Bus (ESB) integration is an architectural approach that facilitates communication and data exchange between various applications and services in a centralized, scalable, and reusable manner. Acting as a middleware layer, an ESB enables different systems—each possibly built on distinct technologies and standards—to interact seamlessly by providing a shared communication backbone.

An ESB manages message routing, data transformation, protocol conversion, and service orchestration, which are essential for integrating systems across an organization. For example, if a company uses separate CRM, ERP, and inventory management systems, the ESB can coordinate and transform data between these systems, enabling real-time updates and consistent workflows without needing direct connections or custom integrations for each system pair.

Key Functions of an ESB include:

• Message Transformation Converting data formats so different applications can interpret and process information.

• Protocol Mediation Translating communication protocols (e.g., HTTP, FTP, JMS) to allow various systems to communicate, even if they don’t share the same communication method.

• Message Routing Directing messages to the correct destinations based on rules or content, enabling selective message delivery.

• Service Orchestration Coordinating multiple services and workflows across systems, ensuring complex processes are completed correctly and in the right order.

Popular ESBs like MuleSoft, IBM Integration Bus, and Apache ServiceMix provide frameworks for implementing this integration model, making it especially valuable for big organizations looking to streamline communications across numerous applications and handle complex integrations in a more manageable, reusable way.

4. Middleware Integration

Middleware integration refers to the use of middleware software to connect different applications and systems, enabling them to communicate and share data seamlessly. Middleware acts as a "middle layer" that manages the interactions between various systems, handling data transformation, message routing, security, and communication protocols translation. This approach is common in complex enterprise environments where direct integration between systems would be inefficient or challenging to maintain.

For example, in a banking system, middleware can integrate customer relationship management (CRM), payment processing, and risk management systems, allowing each to exchange relevant information without needing direct connections. Middleware solutions—such as Enterprise Service Bus (ESB), API gateways, and message brokers—simplify system architecture, reduce redundancies, and make it easier to add or update individual systems without disrupting others.

Overall, middleware integration enables organizations to connect applications efficiently, often in real-time, improving scalability, interoperability, and agility across a networked ecosystem.

Example: An airline uses middleware to integrate its booking system, check-in system, flight management system, and customer service platform. Middleware like IBM WebSphere or Oracle Fusion Middleware manages these integrations.

5. Application Programming Interfaces (API) Integration

Application Programming Interface (API) integration involves connecting different software applications through their APIs to enable them to communicate and share data. APIs define the methods and data formats that applications can use to request and exchange information, serving as a bridge between disparate systems.

API integration facilitates a wide range of functionalities, including data retrieval, updates, and processing tasks across various applications. It enables businesses to leverage third-party services, such as social media platforms, cloud storage, and analytics tools, enhancing their applications without the need for extensive internal development.

Moreover, APIs can be RESTful, SOAP, or GraphQL, each offering different methods for data interaction. Overall, API integration is essential for modern software development, enabling flexibility, scalability, and interoperability across diverse systems and services.

Example: A fintech company integrates its mobile app with various banking systems using APIs provided by each bank. This allows users to access their bank accounts, transfer funds, and view transaction histories within the app.

6. Data Integration

Data Integration, specifically focuses on consolidating and synchronizing data from disparate sources into a single, unified view. It often involves ETL (Extract, Transform, Load) processes or using a data integration tool to consolidate data from multiple sources into a data warehouse or lake, enabling consistent reporting and analytics. For example, data integration might involve pulling sales data from different regional databases into a central data repository to analyze company-wide sales trends.

In essence, while system integration encompasses data, applications, and processes, data integration is a subset focused solely on unifying data to improve accessibility, quality, and insights across platforms.

Example: A healthcare provider integrates patient records from various departments (e.g., radiology, pharmacy, general practice) into a centralized electronic health record (EHR) system. Data integration tools like Informatica or Talend facilitate this process.

7. Business Process Integration (BPI)

Description: Aligns and integrates business processes across different systems. Often involves workflow automation and business process management (BPM) tools.

Example: A manufacturing company uses BPI to automate and streamline its order-to-cash process. This includes integrating order entry, inventory management, production scheduling, and invoicing systems using BPM tools like IBM BPM or Appian.

8. Cloud-Based Integration

Description: Utilizes cloud services to integrate applications and data. Often involves Integration Platform as a Service (iPaaS) solutions.

PubNub offers System Integration Services > try it for free

Example: A multinational corporation uses an iPaaS like PubNub or MuleSoft to integrate its on-premise ERP system with various cloud-based applications such as Salesforce for CRM, Workday for HR, and Amazon Web Services (AWS) for hosting.

These examples illustrate how different types of system integration solutions can be applied in various contexts to ensure that systems work together effectively and efficiently.
